AC Pulse Pneumatic Spot Welding Machine Welder for Cylindrical Battery Welding

ItemNo :
LITH-AC200
MOQ :
1
Color :
optional
Port :
Xiamen Port
Compliance:
CE
Warranty:
2 years
Delivery Time:
5 days
Email :
Louis@lithmachine.com

Contact Now

Product Details

AC Pulse Pneumatic Spot Welding Machine Welder for Cylindrical Battery Welding

INTRODUCTION:

1. This type of AC spot welder utilizes the general mains supply to lower the voltage and increase the electric current. Such kind of low voltage but large current will be transmitted from the electrode to the linked point of two work pieces.

2. On the linkage, due to the resistance of work piece, high temperature will occur so the metal will therefore generates high heat to make the work pieces in molten condition.

Thus, the purpose of welding the two work pieces is achieved.

3. It equipped with advanced 220V AC welding power supply, Suitable battery for pack spot welding and assembly in the factory.

This machine can assembling batteries like 18650, 26650, 21700... and Nickel or Nickel-Plated Steel strips. Which support battery pack like E-Bike, Scooter, electromobile ...

SPECIFICATION:

Welder Power Suppler	220V AC welder
Power Supply	220AC/50Hz
Welding battery	18650, 26650, 21700...
Strip Material	Nickel, Nickel-plated steel
Welding Thickness	0.03~0.2mm
Maximum power output of transformer	15 KVA
Output Maximum Short Circuit Current	3000A
Open circuit voltage	6.5V
Control mode	Constant Current Control
Cooling mode	Forced air cooling
Total weight	24kg

Spot Welding Machinie
Type	Product Name	Features	Picture	Link
Manual	Pneumatic Spot Welding Machine	Welding Thickness:0.03 -0.25mm Air Pressure Range:0.1 - 0.7 Mpa		https://www.lithmachine.com/desk-top-capacitive-discharge-spot-welder-for-battery-tab-and-cylindrical-battery-welding_p366.html
	AC Plus Pneumatic Spot Welding Machine	Welding Thickness:0.03~0.2mm		https://www.lithmachine.com/ac-plus-pneumatic-spot-welding-machine-welder-for-cylindrical-battery-welding_p362.html
	5000A/8000A Pneumatic Inverter DC Spot Welding Machine	Maximum thickness of parallel welding:0.03mm~0.5mm Maximum Output Short Circuit Current:5000A or 8000A		https://www.lithmachine.com/inverter-resistance-welder-18650-power-battery-spot-welder-battery-spot-welding-machine_p442.html
	DC Output Spot Welding Machine	Maximum thickness of parallel welding:0.03mm~0.5mm		https://www.lithmachine.com/High-Precision-DC-Output-Spot-Welding-Machine-Tab-Welder_p364.html
Automatic	Automatc Single Side Spot WeldingMachine(Pneumatic/Electric)	Welding travel:400x500mm Welding Speed:0.35s/point; 2800pcs / hour		https://www.lithmachine.com/automatic-single-side-battery-spot-welding-machine-welder-for-18650-cylindrical-battery-pack_p363.html
	Automatic Single Side Rotary Welding Head Spot Welding Machine(Pneumatic/Electric)	The rotatable welding head can prevent the sticking of the needle. In addition, if it is a nickel strip with different fork directions, the rotating welding head is needed. Welding travel:400x500mm Welding Speed:0.35s/point; 2800pcs / hour		https://www.lithmachine.com/inverter-dc-single-side-automatic-spot-welding-machine-for-cylindrical-battery-pack-assembly_p402.html
	Automatic Double Sides Spot Welding Machine (Pneumatic/Electric)	Welding travel:400x500mm Spot welding speed: 0.3s/point; 5000pcs/h		https://www.lithmachine.com/Automatic-18650-26650-32650-Cylindrical-Battery-Pack-Double-Sides-Spot-Welding-Machine-for-Battery-Assembly_p369.html
