Single Side Automatic Spot Welding Machine For EV Bike Battery Making

Product Categories

Contact Us

  • Contact Person : Louis Yang
  • Email : Louis@lithmachine.com
  • Address : No. 5 Nanshan Road, Huli District, Xiamen City, Fujian Province, China
Single Side Automatic Spot Welding Machine For EV Bike Battery Making Single Side Automatic Spot Welding Machine For EV Bike Battery Making

Single Side Automatic Spot Welding Machine For EV Bike Battery Making

  • ItemNo :

    LITH-SP-02
  • MOQ :

    1
  • Color :

    optional
  • Port :

    Xiamen Port
  • Compliance:

    CE
  • Warranty:

    2 years
  • Delivery Time:

    5 days
  • Email :

    Louis@lithmachine.com
  • Product Details


Single Side Automatic Spot Welding Machine For EV Bike Battery Making



Product Application

Photovoltaic, power battery, NiMH lithium battery and other batteries are connected with nickel alloy strip, aluminum nickel composite strip, wire and guide strip, household electrical parts and guide strip, hardware accessories, copper and silver products, stainless steel peripheral connection, bulb foot welding, electronic parts, all kinds of high and low conductive metal welding, etc.



Features

1) Induct the load voltage, control the voltage in the feedback mode, and realize high-quality welding.

2) Power on mode of pre heat and main heat: preheat before welding to ensure stable welding quality.

3) Keep the continuity of energy density, short welding time, reduce the deformation and discoloration of base metal. (the welding time is controlled in microseconds, and the mode of continuous output)

4) Easy to change from low current to high current, suitable for precision welding.

5) The upper and lower limits of current can be set to judge whether the welding quality is good or not, which is suitable for the welding automation platform.

6) The welding current will rise with the power on time to ensure the welding effect.

7) Stable control system

8) High configuration regulating device

9) High precision working procedure

10) High cost performance of products


Performance features:

1. Touch screen display, more convenient operation and clearer display

2. Three file programming modes, manual input, array, CAD drawing import, simple and fast response to various complex program editing

3. The welding head has the function of air cooling or water cooling, which can effectively reduce the influence of spot welding needle temperature on welding quality

4. It can store up to 99 groups of files, which is easy to call and does not need complicated process of line changing and machine adjusting

5. The spot welding program of a side and B side of fixture can be switched.


Specifications

Power Supply

AC 220V±10% 50Hz

Electric Current

DC

Welding Mode

Inverter DC

Welding Current

5000A or 8000A optional

Power Form

Automatic

Y-axis Travel

400mm

X-axis Travel

500mm

Spot Welding Speed

0.35s/point; 2800pcs / hour

Fast Speed of Motor Drive

1000mm/s

Number of Cores Loaded

X direction: 26

Y direction: 26

(standard:18650 cell)

Number of file groups that can be stored

99 group

Operating System

Embedded system + man machine interface

Transmission mode

Stepping + imported precision linear guide rail, optional servo + screw rod)

Equipment air pressure

0.4-0.7Mpa

Weight

200kg

Size

900*900*1650mm


Spot Welding Machine

Type

Product Name

Features


Link

Manual

Pneumatic Spot WeldinMachine

Welding Thickness:0.03 -0.25mm

Air Pressure Range:0.1 - 0.7 Mpa





https://www.lithmachine.com/desk-top-capacitive-discharge-spot-welder-for-battery-tab-and-cylindrical-battery-welding_p366.html

AC Plus Pneumatic Spot Welding Machine

Welding Thickness:0.03~0.2mm



https://www.lithmachine.com/ac-plus-pneumatic-spot-welding-machine-welder-for-cylindrical-battery-welding_p362.html

5000A/8000A Pneumatic Inverter DC Spot Welding Machine

Maximum thickness of parallel welding:0.03mm~0.5mm

Maximum Output Short Circuit Current:5000A  or 8000A



 https://www.lithmachine.com/inverter-resistance-welder-18650-power-battery-spot-welder-battery-spot-welding-machine_p442.html

DC Output Spot Welding Machine

Maximum thickness of parallel

welding:0.03mm~0.5mm



https://www.lithmachine.com/High-Precision-DC-Output-Spot-Welding-Machine-Tab-Welder_p364.html

Automatic

Automatc Single Side Spot WeldingMachine(Pneumatic/Electric)

Welding travel:400x500mm

Welding Speed:0.35s/point; 2800pcs / hour



https://www.lithmachine.com/automatic-single-side-battery-spot-welding-machine-welder-for-18650-cylindrical-battery-pack_p363.html

Automatic Single Side Rotary Welding Head Spot Welding Machine(Pneumatic/Electric)

The rotatable welding head can prevent the sticking of the needle. In addition, if it is a nickel strip with different fork directions, the rotating welding head is needed. Welding travel:400x500mm Welding Speed:0.35s/point; 2800pcs / hour



https://www.lithmachine.com/inverter-dc-single-side-automatic-spot-welding-machine-for-cylindrical-battery-pack-assembly_p402.html

Automatic Double Sides Spot Welding Machine (Pneumatic/Electric)

Welding travel:400x500mm Spot welding speed: 0.3s/point; 5000pcs/h



https://www.lithmachine.com/Automatic-18650-26650-32650-Cylindrical-Battery-Pack-Double-Sides-Spot-Welding-Machine-for-Battery-Assembly_p369.html










                                            single side spot welder




Related Machine

Battery pack assembly line






PACKAGE:

     1 Standard exported package: Internal anticollision protection, external export wooden box packaging.

     2 Shipping by express, by air, by sea according to customers' requirements to find the most suitable way.

     3 Responsible for the damage during the shipping process, will change the damage part for you for free.



DELIVERY TIME:15-20 days after confirming order,detail delivery date should be decided according to production season and order quantity
