ItemNo :
LITH-ZS-1001MOQ :
1Place of Origin:
ChinaColor :
optionalPort :
Xiamen PortCompliance:
CEWarranty:
2 yearsDelivery Time:
5 daysEmail :
Louis@lithmachine.comBattery Safety Needle Penetration Tester for Thermal Analysis and Impact Testing
I. Product Overview:
This testing machine is designed to simulate the puncture scenario for batteries under controlled environmental conditions. Tests are conducted at a temperature of 20℃ ± 5℃. A battery equipped with a thermocouple (fixed on the large surface of the battery) is placed in a ventilated chamber, and a rust-free steel needle with a diameter of 2-8mm penetrates the center of the battery’s largest surface at a speed of 10-40mm/s. The needle remains in place for an arbitrary duration as per test requirements.
II. Compliance Standards:
MT/T1051
GB/T18332
GB/T8897.4
QC/T473/744
QC/T743
YD/B032
III. Technical Parameters:
|
Steel Needle |
Diameter: φ3mm–φ8mm Length: 100mm (customizable). Material: High-temperature resistant steel. |
|
Needle Stroke |
Options: 200mm or 300mm. |
|
Battery Clamping Distance |
200mm |
|
Unit Conversion |
Kg, N, LB |
|
Needle Penetration Speed |
Range: 10–40mm/s (customizable). |
|
Needle Force Range |
1–20KN (optional) |
|
Force Display |
Options: LCD screen or touch screen display. |
|
Force Measurement Accuracy |
±1% |
|
Drive Method |
Pneumatic drive or hydraulic drive |
|
Chamber Material |
Inner chamber: Stainless steel Outer chamber: Cold-rolled steel, powder-coated finish |
|
Special Features |
Rear exhaust vent and pressure relief system Internal lighting system |
|
Weight |
Approximately 100kg |
|
Power Supply |
Single-phase, 220V, 50Hz |
PACKAGE:
1 Standard exported package: Internal anticollision protection, external export wooden box packaging.
2 Shipping by express, by air, by sea according to customers' requirements to find the most suitable way.
3 Responsible for the damage during the shipping process, will change the damaged part for you for free.
DELIVERY TIME:15-20 days after confirming the order, detail delivery date should be decided according to
production season and order quantity.
