Simple PVC/PET Tape Die Cutter Punching Cutting Machine
Performance characteristics
1. Round knife die cutting, and professional round knife machine die universal, convenient and efficient;
2. Round cutter holder can be equipped with slitter knife, precision slitter full or half broken;
3. It can be equipped with round knife laminating roller to complete the function of three-station laminating machine;
4. Full magnetic powder tension control, the material tension control is more gentle and stable.
Scope of application
PVC, PET, double-sided tape, protective film, sponge, foam and other materials of circular knife forming, slitting and bonding, waste removal
Extended features
1, multi-station simple round knife machine
2, round knife slitting molding function
3, servo drive high precision round knife machine
4, straight knife hand tear a molding
Technical parameters
|
Machine type |
LITH-YF-320 |
LITH-YF-450 |
|
Film coated seat |
1 group/2 group/3 group |
1 group/2 group/3 group |
|
Circular cutter assembly |
1 group/2 group |
1 group/2 group |
|
Feed width |
≤280mm |
≤380mm |
|
Blade width |
≤250mm |
≤350mm |
|
Maximum speed |
0～45m/min |
0～45m/min |
|
Overall dimension |
3100*1600*1900mm |
3100*1700*1900mm |
|
Voltage power |
220V/1.5KW/AC |
380V/1.5KW/AC |
|
Machine weight |
400kg |
450kg |
PACKAGE:
1 Standard exported package: Internal anticollision protection, external export wooden box packaging.
2 Shipping by express, by air, by sea according to customers' requirements to find the most suitable way.
3 Responsible for the damage during the shipping process, will change the damaged part for you for free.
DELIVERY TIME:15-20 days after confirming the order, detail delivery date should be decided according to
production season and order quantity.
