Manual Integrated Laminating Flat Hot Press 300C to 500C

Manual Integrated Laminating Flat Hot Press 300C to 500C

  • Product Details

Manual Integrated Laminating Flat Hot Press 300C to 500C


Features

New RYJ-600E series manual hot press is our company combined with market demand, developed a new small tonnage, widened type, integrated, double plate hot press. This machine satisfied to stress more stringent control accuracy, and wide size sample hot-pressing experimental users, for powder, rubber, plastic film and so on some sample experiment of high temperature solid samples can also be used as a  small rheometer, is now widely used in scientific research, teaching, persistence,medicine, catalysis, chemical and other industries, can replace similar imported products.




Main technical parameters

Product name

RYJ-600E1

RYJ-600E2

RYJ-600EG1

RYJ-600EG2

Pressure range

0-10T(0-30Mpa)

Pressure conversion

1t=3Mpa/1Mpa=0.33t

Piston diameter

Dia65mm chrome plating cylinder

Type of pressure gauge

Digital display, range 0.001-40.000Mpa, display precision 0.001mpa

Pressure mode

Manual pressure

Temperature controller type

XNNETS PLC programmed temperature controller (double

temperature controller)

Temperature control range

RT-600.0/0.1

Type of hot pressing die

Double die heating up and down (polished surface)

Heating die size

180*180mm

200*200mm

180*180mm

200*200mm

Temperature of hot pressing die

RT-300

RT-500

Heating die cooling method

Cooling by natural or water cooler

Cooling by natural or water cooler

Equipment insulation Mode

 Imported heat shield

Imported heat insulation board + stainless steel water cooling cycle heat insulation board

Power

220V/1800W

220V/2500W

Overall structure

One-piece construction

Size of  the machine

280*320*520mm(The weight of the water cooler is not included)

Weight

About 80-95kg

Model specification

Water cooling machine (optional)




1.  We supply machines with battery technology support.

2.  We supply full set of lithium battery equipment for lab research, pilot scale research and production line.


hydraulic press machine


1 Standard exported package: Internal anticollision protection, external export wooden box packaging.

2 Shipping by express, by air, by sea according to customers' requirements to find the most suitable way.

3 Responsible for the damage during the shipping process, will change the damage part for you for free.
