Double Coated Li-NCM (5:2:3) Aluminum Foil for Cathode of Li-ion Battery

Double Coated Li-NCM (5:2:3) Aluminum Foil for Cathode of Li-ion Battery

  • Product Details


Double Coated Li-NCM (5:2:3) Aluminum Foil for Cathode of Li-ion Battery


This electrode sheet is based on Aluminum foil coated by Lithium Nickel Manganese Cobalt Oxide in double side and is used as the cathode of Li-Ion battery -- 5 sheets /bag


SPECIFICATIONS

  • Material:  LiNiCoMnO2  ( 5:2:3)
  • Current collector (substrate): Aluminum foil ( 15 microns)
  • Cathode material: Lithium Nickel Manganese Cobalt Oxide
  • Double sides active material density: 242g/m²
  • Active Material Weight: 9.642g
  • Active Material Proportion in Powder: 94.2%
  • Specific Capacity: 155 mAh/g
  • Average Cycle Life: 500 Cycles @ 0.2C Charging/Discharging Rate
  • Length: 241mm
  • Width: 200mm
  • Thickness: 103um +/- 5um
    Foil Thickness: 15um +/- 5um
    Coating Thickness: 88um +/- 10um (double side coated)
  • Net Weight: 27.5g
  • Double side coated
  • Qty: 5 sheets/bag
  • Note:  The electrode sheet shall be stored in a vacuum box, a vacuum oven or a glove box to avoid degradation










PACKAGE:

  1 Standard exported package: Internal anticollision protection, external export wooden box packaging.

  2 Shipping by express, by air, by sea according to customers' requirements to find the most suitable way.

  3 Responsible for the damage during the shipping process, will change the damaged part for you for free.



DELIVERY TIME:15-20 days after confirming the order, detail delivery date should be decided according to

production season and order quantity.
