5L Compact Filtration/Sieving System for Electrode Slurry

5L Compact Filtration/Sieving System for Electrode Slurry

  • Product Details

5L Compact Filtration/Sieving System for Electrode Slurry




Product introduction: This filter device is mainly used in a special filter designed for laboratory samples to filter out various hard particles with a particle size of not less than 124 microns. The overall design is beautiful, flexible and convenient to use.



Main features:

* High filtration accuracy, up to 124 microns, equipped with two particle filters for filtering positive and negative.

* All SUS304 stainless steel design, good corrosion resistance, easy to clean and clean.

* The filter net with a large filtering area makes the pressure loss very low, and the equipment is durable.

* Small size and easy operation.

* Beautiful appearance, easy maintenance, molding and other advantages.


Technical Parameters

* Filter size: 500 × 500 × 510mm

* Weight: 10Kg

* Power adapter: AC 220V ± 10% 50HZ,

* Absolute vacuum: 65KPa

* Air pump flow: 5L / Min

* With filter: 100 mesh filter (optional)

* Optional filter: below 1000 mesh

* Capacity: 5L





Coin Cell Process:

Materilas → Powder Processing  →Powder Grinding Mill → Vacuum Mixing  → Electrode Coating → Roll Press  → Vacuum Drying  → Disc Cutter → Electrolyte Injection  → Crimping Machine  → Battery Analyzer



For the coin cell Assembly, we also recommend you the following items:











PACKAGE:

  1 Standard exported package: Internal anticollision protection, external export wooden box packaging.

  2 Shipping by express, by air, by sea according to customers' requirements to find the most suitable way.

  3 Responsible for the damage during the shipping process, will change the damaged part for you for free.



DELIVERY TIME:15-20 days after confirming the order, detail delivery date should be decided according to

production season and order quantity.
