Semi-automatic Slitting Machine With Different Model Cutter Blade

Semi-automatic Slitting Machine With Different Model Cutter Blade

  • Product Details




Semi-automatic Slitting Machine With Different Model Cutter Blade


1 LITH-DYG-110A model Battery electrode slitting machine is a semi-automatic slitting machine for preparing electrode of cylinder batteries and prismatic batteries in R&D laboratories and production line.

2 The slitting machine can slit electrode with width up to 400mm, and with finished slitting width from 20mm to 400mm with different model cutter blade.


3 This equipment is suitable for rechargeable lithium batteries cathode and anode electrode of the longitudinal cutting, the electrode of the base material can be aluminum foil and copper foil, sliced edge tidy, high dimensional accuracy, no burr, it is an important equipment in plate processing.



SPECIFICATIONS:

Model

Battery Electrode Slitting Machine      LITH-DYG-110A

Source voltage

AC 110V-220V, Customized, 50HZ

Power

800W

Warranty

One year limited warranty and lifetime support

Slitting mode

Single knife hobbing

Knife type

Upper and lower round knife

Slitting width

20-500mm

Slitting thickness

100-300um

Hob diameter

 Φ80 mm

Slitting speed

10m/min, Adjustable






Battery Electrode Slitting Machine

Battery Electrode Slitting Machine


Battery Electrode Slitting Machine









PACKAGE:

  1 Standard exported package: Internal anticollision protection, external export wooden box packaging.

  2 Shipping by express, by air, by sea according to customers' requirements to find the most suitable way.

  3 Responsible for the damage during the shipping process, will change the damaged part for you for free.



DELIVERY TIME:15-20 days after confirming the order, detail delivery date should be decided according to

production season and order quantity.
