Louis@lithmachine.comLab Battery Electrode Continuous Coating Machine Coater For Lithium Battery
Feature
The desktop continuous coating machine is a small roll to rolling coating machine for lab research, it is assembled by high high precision coating device, suitable for institutions, university and factory pilot scale battery research work.
Specifications
|
Model |
Roll to Roll Continuous Coating Machine LITH-TMJ-180C |
|
Source voltage |
AC 220V/110V, 50HZ/60HZ |
|
Power |
400W |
|
Warranty |
One Year limited warranty with lifetime support |
|
Suitable material thickness |
Aluminum foil : 0.01-0.03mm Copper foil : 0.006-0.020mm |
|
Max electrode width |
50-180mm |
|
Coating speed |
0-2m/min, adjustable |
|
Max baking temperature |
100℃ ,PID control mode |
|
Coating thickness |
0.01mm-2mm |
|
Coating thickness accuracy |
0.01mm |
|
Dimension |
800* 350 * 580 mm |
|
Weight |
About 50kg |
1 Standard exported package: Internal anticollision protection, external export wooden box packaging.
2 Shipping by express, by air, by sea according to customers' requirements to find the most suitable way.
3 Responsible for the damage during the shipping process, will change the damaged part for you for free.
DELIVERY TIME:15-20 days after confirming the order, detail delivery date should be decided according to
production season and order quantity.
