Lab Battery Electrode Continuous Coating Coater Machine With Drying Oven

Lab Battery Electrode Continuous Coating Coater Machine With Drying Oven

  • Product Details

Lab Battery Electrode Continuous Coating Coater Machine With Drying Oven


The desktop continuous coating machine is a small roll to rolling coating machine for lab research, it is assembled by high high precision coating device, suitable for institutions, university and factory pilot scale battery research work.


Model

Roll to Roll Continuous Coating  Machine  LITH-TMJ-180C

Source voltage

AC 220V/110V, 50HZ/60HZ

Power

400W

Warranty

One Year limited warranty with lifetime support

Suitable material thickness

Aluminum foil : 0.01-0.03mm

Copper foil : 0.006-0.020mm

Max electrode width

50-180mm

Coating speed

0-2m/min, adjustable

Max baking temperature

100℃ ,PID control mode

Coating thickness

0.01mm-2mm

Coating thickness accuracy

0.01mm

Dimension

800* 350 * 580 mm

Weight

About 50kg


Roll to Roll coater machine


coating machine


coater machine

Coin Cell Assembly








PACKAGE:

  1 Standard exported package: Internal anticollision protection, external export wooden box packaging.

  2 Shipping by express, by air, by sea according to customers' requirements to find the most suitable way.

  3 Responsible for the damage during the shipping process, will change the damaged part for you for free.



DELIVERY TIME:15-20 days after confirming the order, detail delivery date should be decided according to

production season and order quantity.
