Compact Filtration/Sieving System (750mL) for Electrode Slurry

  • Product Details

Compact Filtration/Sieving System (750mL) for Electrode Slurry


slurry filtration system is designed for use with the preparation of battery electrode slurries. It comes with two filters for removing particle sizes with dia>120or>100 micrometer.  A SS304 slurry container together with a compact design allows for ease of operation and maximum flexibility in laboratory settings.

SPECIFICATIONS

Power Requirements

· Input: 100 - 240V AC; 50/60 Hz

· Output: DC12V, 0.4A

· Power plug configured for US electrical sockets (CE Certified) is included; plugs for other countries can be found

Structure

Made of SS304

Pump Flow Rate

3L/min

Absolute Vacuum Level

65kPa

Capacity

750mL

Filtration

· 2 Filters included

· Filtration Pore Sizes: 100 mesh & 120 mesh

Measuring Cup

· One stainless steel cup is included for measuring slurry up to 700ml or 24oz

· Scribe lines on the inside facilitate the measurement

Filter Container Dimensions

140mm x 70mm x150mm

Air Generator Dimensions

150mm x 150mm x 200mm

Net Weight

5kg

Warranty

· One year limited with lifetime support



Sieving System



Coin Cell Process:

Materilas → Powder Processing  →Powder Grinding Mill → Vacuum Mixing  → Electrode Coating → Roll Press  → Vacuum Drying  → Disc Cutter → Electrolyte Injection  → Crimping Machine  → Battery Analyzer



For the coin cell Assembly, we also recommend you the following items:











PACKAGE:

  1 Standard exported package: Internal anticollision protection, external export wooden box packaging.

  2 Shipping by express, by air, by sea according to customers' requirements to find the most suitable way.

  3 Responsible for the damage during the shipping process, will change the damaged part for you for free.



DELIVERY TIME:15-20 days after confirming the order, detail delivery date should be decided according to

production season and order quantity.
